Stage Micrometer

This stage micrometer is a glass microscope calibration slide with a 1 mm scale divided into 100 divisions. Each division represents 0.01 mm (10 µm), providing a reference for calibrating a compatible eyepiece graticule.Compare the slide scale with the eyepiece scale at your selected objective magnification, then record the calibration for subsequent specimen measurements. Repeat calibration when changing objectives or other settings that affect image...

Rs.1,690.00 ~~Rs.1,950.00~~

Brand:: Lab Store
Tags:: Calibration Slide, Eyepiece Graticule, Microscope Calibration, Microscopy Accessories, Stage Micrometer

Compare the slide scale with the eyepiece scale at your selected objective magnification, then record the calibration for subsequent specimen measurements. Repeat calibration when changing objectives or other settings that affect image scale.

Product specifications

Product type: stage micrometer calibration slide.
Material: glass.
Scale length: 1 mm.
Number of divisions: 100.
Division size: 0.01 mm (10 µm).
Listed slide dimensions: 75 × 25 mm.

Applications

Eyepiece graticule calibration, quantitative microscopy, cell and tissue measurement, and biology or materials-science teaching practicals.

Compatibility and care

Confirm that the slide fits your microscope stage and that the reference scale suits your measurement method. Calibration tolerances and certification are not specified in this listing. Handle by the edges and protect the scale from scratches and contamination.
